Open source SPM Controller, Model MK2-A810

4 200$ (CAN)
This Open source SPM Controler has been specially designed to meet the requirements of the GXSM, the Gnome X Scanning Microscopy project.

"Dancing Molecules on Graphene", by Percy Zahl, data acquired with the gxsm SPM

Main characteristics
• 8 analog I/O capable of operating at up to 150 kHz with a +-10V dynamic range
• 2/16-bit counters inputs
• 16 individually configurable GPIOs
• Low noise and very high DC stability
• Very low input-output group-delay
• 5502 DSP from Texas Instrument running at 300 MHz
• SPARTAN 3 FPGA from Xilinx
• High Speed USB interface controller

Advanced SPM features can be implemented using the 16 individually configurable GPIOs and the two 16-bit counters. These counters are synchronized with the analog sampling and can be used as simple pulse counters or Quadrature Encoder Pulse (QEP) counters.

Download
Open source SPM Spec Sheet SR2-A810 Installer (Labview 2009) (Last Update: august 2010)

Migration to SR2_NG (for a x64 compatibility):

More information about the SR2 to SR2_NG migration Download migration tool
SR2_NG software installer (the same software is used for SR3, SR3Pro and SR2_NG)

Publication:
P. Zahl, T. Wagner, R. Möller and A. Klust, "Open source scanning probe microscopy control software package Gxsm", J. Vac. Sci. Technol. B 28 (2010). Read now: Link to this article.

Free complete SPM software (Linux/Windows) is available at gxsm.sourceforge.net & sranger.sf.net

Users: Canada, US, Europe, Asia

SPM Reference List
